FUEL TREATMENT PLANT

Automatic filtration at scheduled times

Yeni

APPLICATION

  • Automatic fuel treatment system for tanks.
  • Automatic and programmable on and off, to remove water and microparticles. It performs a homogenisation and oxygenation of the fuel. It prevents the creation of bacteria, algae and mildew that can damage the installation and vehicles or machines to which it is supplied.


The importance of installing a fuel treatment system

  • It avoids the creation of sludges in the tank bottom.


With a periodical filtration, the particles and water in suspension are eliminated, avoiding its sedimentation. It prevents from an expensive tank cleaning. To clean the tank it is required to stop the installation, completely empty the tank, degas it and clean it manually. It is a very expensive and high-risk process.

  • It avoids the creation of bacteria.


The creation of bacteria in diesel tanks is increasingly common. This is due to that currently the regulations allow mix diesel with 7 percent of biodiesel. This increases the presence of water and the consequent appearance of bacteria. Bacteria are very difficult to eliminate and cause problems in the machines to which it is supplied and in the installation itself.

  • It protects the machines or the vehicles that use the fuel.


The modern systems of combustion are very sensitive to the microimpurities. The diesel must be microfiltered in order to protect the injectors.

COMPOSED OF

  • Self-suction blade pump
  • 1 filter for particles + 1 water absorbent filter
  • ON/OFF Timer
  • IP-55 switchboard composed of
    • Main MCB
    • Differential
    • Individual motor-guard switch
    • Multifunction timer
    • ON/OFF swithc with removable key
TECHNICAL FEATURES
 Flow
(l/min)
Cartridge*ViewerDimensions
(mm)
Weight
(kg)
150 · Fuel Treatment System4515 micron water absorbent-550x260x50019
150 EExd · Fuel Treatment System4515 micron water absorbent-550x260x50022
300 EExd · Fuel Treatment System14015 micron water absorbentVisual saturation viewer670x400x76067.5
300x2 EExd · Fuel Treatment System14050 + 15 micron absorbentVisual saturation viewer1,000x400x76084.5
450x2 EExd · Fuel Treatment System14050 + 15 micron absorbentVisual saturation viewer1,000x400x1,240 104.5

* There are other filtering element available · Available single-phase and triphase motors
