- It is suitable for particle microfiltration from 2.5 µm (micron) (fibreglass filtering element), from 3 to 15 µm (micron) (the filtering paper is water absorbent) or 50 µm (micron). It is possible to drain through the manual drain valve placed in the microfilter bottom.
- This microfilter has been made for the diesel, petrol, kerosene, AVGAS, JET A-1, and, in general, hydrocarbon liquid microfiltration.
- Differential manometer where you can see when the filter level is exceed.
- The microfilter is supplied with the filtering element installed.
Technical features:
- Filtration:
- 2.5 µm (micron) · fibreglass (mod. FG-300/2.5)
- 3 µm (micron) · water absorbent (mod. FG-300/3)
- 5 µm (micron) · water absorbent (mod. FG-300/5)
- 15 µm (micron) · water absorbent (mod. FG-300/15)
- 50 µm (micron) (mod. FG-300/50)
- Capacity: 15 litres in the housing interior
- Flow: 300 l/min
- Microfilter cover and body: Aluminium
- Differential manometer
- Inlet / Outlet Connections: F2" BSP or flange
- Manual lower drain valve
- Superior drain valve to eliminate the inner air of the filter
- Installation: in the suction or delivery of the pumping kit
- Maximum operating pressure: 6 bar
- Maximum housing pressure: 10 bar
Size and weight (approx.):
- Size: Ø254x312x670 mm (Ø x base x height)
- Weight: 17 kg
