Industrial pump dispenser
Yanacaq / Industrial pump dispenser / SHK / SH-Plus · SIMPLE

SHK / SH-Plus · SIMPLE

GK-7 Control | 80 · 110 l/min

Dizel Dizel
Benzin Benzin

Yeni

  • Supply kits with ATEX components, special for installations of diesel, petrol, kerosene supply.
  • This kit is composed of high accuracy hydraulic group and the GK-7 or GK-7Plus own consumption controller.

Composed of:

CHASSIS:

  • Sides in stainless steel
  • Doors made of aluminium and the remainder frame made of steel
  • Special treatment to protect against corrosion and QUALICOAT CLASS 1 powder coating finishing
  • Weatherproof

HYDRAULIC GROUP composed of:

  • Pump: Self-suction, eccentric with self-adjusting blades with gas separator. Flow: 80 or 110 l/min · Recirculation bypass valve · filter
  • Meter: made of aluminium of 4 pistons with positive displacement · Accuracy: ±0.2 % · Pulser of 2 channels of 100 pulses per litre · Mechanical totalisator
  • EExd Motor with ATEX certificate · IP-55 protection:
    • Triphase 80 l/min · 1 kW 230/400 VAC
    • Single-phase 80 l/min: 1 kW 230 VAC
    • Triphase 110 l/min: 1.5 kW 230/400 VAC

CONTROLLER:

  • GK-7Plus: Communicate automatically and wirelessly, through 2G, to the cloud software www.dieselplus.net
  • GK-7: You will need to purchase a communication kit, which includes the necessary software and hardware to connect your dispenser to a PC

It is supplied with:

  • 4 m delivery diesel double layer hose with 1" adapters in both ends
  • Automatic nozzle

Size and weight (approx.):

  • Dim.: 800x400x1500 mm (L x W x H)
  • Weight: 110 kg

Flow rate: 80 l/min

SH-80Plus-130 users · 1000 services · triphase
42090-CF00000
SH-80Plus-1000 users · 1000 services · triphase
42090-CF00001
SH-80Plus-130 users · 1,000 services · single-phase
42030-CF00000
SH-80Plus-1,000 users · 1,000 services · single-phase
42030-CF00001
Flow rate: 110 l/min
SH-110Plus-130 users · 1,000 services · triphase
42130-CF00000
SH-110Plus-1,000 users · 1,000 services · triphase
42130-CF00001
Flow rate: 80 l/min
SHK-80-130 users · 500 services · triphase
42080-CF00000
SHK-80-1,000 users · 1,000 services · triphase
42080-CF00001
SHK-80-130 users · 1,000 services · single-phase
42020-CF00000
SHK-80-1000 users · 1000 services · single-phase
42020-CF00001
Flow rate: 110 l/min
SHK-110-130 users · 500 services - three-phase
42120-CF00000
SHK-110-1,000 users · 1,000 services · triphase
42120-CF00001
(+) TICKET THERMAL PRINTER (internal)
FE006002
(+) PROTECTION SUNSHIELD
FE016001
OPTIONAL IDENTIFICATION SYSTEMS
(+) Proximity card reader
FE017002
(+) Magnetic card reader
FE017003
Optional:
- Flexible suction tube for supply kit with 2“ flange
807610002
- 4 m Ø19 mm antistatic unleaded petrol hose with adapters in both ends
803406101
- GK-7 identification key (10-unit pack)
251201002
- High anchorage base
268904021
