MGI-250 · PULSER

±0.5% · F1" or 1 1/2"

Lubricant Lubricant
Dizel Dizel
MGI-250 1" · Pulser
32511
MGI-250 1 1/2" · Pulser
325100200

Pulser for its in-line assembly, making easier the exact information of the fluid management and control systems.

Technical data:

  • Flow (approx.):
    • 10-250 l/min (diesel)
    • 10-150 l/min (lubricant
  • Viscosity: 2-2000 cSt
  • Voltage: 28 VDC
  • Max. power: 8 W
  • Maximum current: 100 mA
  • Accuracy: ±0.5%
  • Maximum pressure: 45 bar
  • Min./max. temperature with Reeds: -10ºC / +90ºC
  • Two channels: 11 pulses per litre and channel
  • Inlet / outlet connection: F1" or 1 1/2" BSP (flange)
  • Housing and cover: Aluminium
Size and weight (approx.):

MGI-250 F1"

  • Dim.: 159x100x141 mm (length x width x height)
  • Weight: 2.3 kg

MGI-250 F1 1/2"

  • Dim.: 183x100x141 mm (length x width x height)
  • Weight: 2.5 kg
