STE GED · DOUBLE
ELECTRONIC · ±0.2 %
USE
- Electronic double supply kits with ATEX components special for supply installations of diesel, petrol and kerosene.
- Composed of two high accuracy hydraulic groups
- It is possible to connect it to a GK-7M controller through the RS485 communication bus and the GESPASA communication protocol.
- They are suitable for transport companies, private vehicle fleet, agricultural companies, public works and so on.
Composed of:
CHASSIS:
- Main body made of stainless steel, doors and heading made of steel with polyurethane paint
- Special interior and exterior corrosion treatment
- Weatherproof
2 Hydraulic groups composed of:
- Pump: Self-suction, eccentric of self-adjusting blades with gas separator · Free flow: 80 l/min or 110 l/min · recirculation bypass valve · filter
- Meter: 4-piston made of aluminium with positive movement · Accuracy: ±0.2 % · 2-channel pulser of 100 pulses per litre and mechanical totalisator
- EExd Motor with ATEX certificate · IP-55 protection:
- Triphase 80 l/min: 1 kW 230/400 VAC
- Single-phase 80 l/min: 1 kW 230 VAC
- Triphase 110 l/min: 1,5 kW 230/400 VAC
2 ELECTRONIC DISPLAYS
- GE · 6-digit electronic tropicalised console with luminous display at 230 V
It is supplied with:
- 2 x 4 m Ø25 mm double layer delivery antistatic hose special for diesel with adapters
- 2 automatic nozzles
Size and weight (aprox.):
- Dim.: 800x400x1,500 mm (L x W x H)
- Weight: 110 kg
